The VGE-T40EX 2 Post Lift is a heavy-duty, electro-hydraulic vehicle lift engineered to handle up to 4 tonnes — making it ideal for professional garages, MOT stations, tyre shops, fleet service centres, and even home enthusiasts who need a reliable, workshop-grade lifting solution. With dual hydraulic cylinders, electromagnetic safety locks, telescopic lifting arms, and multiple built-in fail-safes, it delivers smooth, stable lifting for cars, SUVs, 4×4s and light commercial vehicles.
Whether you're performing under-body repairs, brake/exhaust work, wheel alignment preparation, or full servicing, the VGE-T40EX provides safe, ergonomic access to the vehicle underside — boosting productivity and reducing workshop fatigue.
Whether you're performing under-body repairs, brake/exhaust work, wheel alignment preparation, or full servicing, the VGE-T40EX provides safe, ergonomic access to the vehicle underside — boosting productivity and reducing workshop fatigue.
Features & Benefits
- 4-tonne lifting capacity — Supports cars, SUVs, 4×4s and light commercial vans with ease.
Benefit: One lift handles nearly all day-to-day workshop vehicles without strain or risk of overload. - Dual hydraulic cylinders with direct-drive system — Synchronisation cable ensures both sides lift evenly.
Benefit: Guarantees level lifting, smooth operation, and avoids instability caused by uneven raising. - Automatic dual-point electromagnetic lock release — Safety locks engage automatically during lifting and release at the push of a button.
Benefit: Faster, safer operation with no manual lock handling — reducing errors and saving time. - Two-stage telescopic arms with adjustable lifting pads — Optional height extensions available for varied vehicles.
Benefit: Easily accommodates different chassis types, from small cars to high-clearance vans. - Multiple safety systems integrated — Overload valve, hydraulic parachute valves, height-limit switch, and door-protection rubbers.
Benefit: Enhanced operator safety in all operating conditions, even in the event of hydraulic failure. - Emergency manual lowering with adjustable descent — Allows controlled lowering even during power loss.
Benefit: Prevents downtime and ensures vehicles can be safely recovered if an electrical fault occurs. - Heavy-duty welded structure with powder-coated finish — Galvanised moving parts for long service life.
Benefit: Highly durable, low-maintenance, and resistant to corrosion — ideal for busy workshops. - 12 Months Standard Warranty 24 Months Parts Warranty (subject to service plan)
| Lifting Capacity | 4000 kg (4 tonne) |
| Maximum Lifting Height | Approx. 1900 – 1930 mm (depending on pad configuration) |
| Minimum Pad Height | Approx. 100 – 110 mm |
| Arm Type | Two-stage telescopic arms with adjustable pads; optional extension adapters |
| Lifting Mechanism | Dual hydraulic cylinders, direct drive, synchronisation cable |
| Safety & Locking System | Dual-point electromagnetic locks, overload relief valve, parachute valves, height-limit switch, door-protection rubbers |
| Power Supply | 240 V Single-Phase (Optional: 415 V Three-Phase) |
| Emergency Lowering | Manual lowering function with controlled descent speed |
| Construction & Finish | Welded steel frame, galvanised moving parts, powder-coated finish |
| Certification & Compliance | CE / UKCA compliant — meets automotive lift safety standards |
