ATH Heinl Four Lift 55AP Electro-Hydraulic 4 Post Lift
In stock
SKU
ATH Heinl Four Lift 55AP Electro-Hydraulic 4 Post Lift
£9,695.00
£11,634.00
Finance from £50.82 +VAT per week*
- Electro-hydraulic 4-post lift with quick lift unit and load-dependent lowering function
- Central operating unit, including unit cover
- ATH Four Lift 55AP: Level running rail with integrated wheel alignment kit
- ATH Four Lift 55P: level running rail, optional wheel alignment kit
- Precisely levelable notch and rail system
- Safety Control: Electropneumatic safety locks that automatically unlock with lifting and lowering
- Safety Lock: ability to lock the load on to the safety mechanism
- Multifunctional mounting via continuously adjustable rails
- Perfect platform protection made of special polymer and double powder coating
Technical Data
| Color | Anthrazitgrau / Schwarz |
| Rated load capacity | 5.500 kg |
| Lifting height (max.) | 2.045 mm |
| Drive-on height | 275 mm |
| Total platform length | 5,600 mm |
| Total platform width | 650 mm |
| Driving power | 4 kW |
| Lifting/Lowering time | ca. 45 s |
| Power supply voltage | 3x 400V / C16A |
| Concrete strength | min. C20/25 (7.400 x 3.900 x 200 mm) |
Products You May Also Consider
FAQ About ATH M52 + A34 Assist Arm Tyre Changer – Heavy-Duty Tilt-Back Machine for Run-Flat & UHP Tyres (14"–26")
What types of tyres is the M52 + A34 designed for?
The M52 + A34 is ideal for run-flat, ultra-high-performance (UHP), low-profile, and stiff-sidewall tyres.
The A34 assist arm provides additional leverage and control, making difficult tyre changes faster, safer, and more efficient.
What wheel sizes does the ATH M52 + A34 support?
The machine supports:
• 14″–26″ internal clamping
• 12″–24″ external clamping
• Up to 13″ rim width
• Maximum wheel diameter approx. 1,050 mm
This range covers standard car wheels, large SUV wheels, and van tyres.
• 14″–26″ internal clamping
• 12″–24″ external clamping
• Up to 13″ rim width
• Maximum wheel diameter approx. 1,050 mm
This range covers standard car wheels, large SUV wheels, and van tyres.
Does the M52 + A34 require three-phase power?
Yes — the M52 + A34 operates on a 400V three-phase power supply.
Workshops without three-phase will need the appropriate electrical infrastructure.
The machine also requires a stable 10-bar compressed air supply for pneumatic operation.
